Ultrafine grinding mill
Ultrafine grinding mill
info:The core structure consists of the machine body, crushing blades, and fan system, achieving multiple crushing effects such as impact and grinding through high-speed rotation. Suitable for tough and brittle materials such as wood chips, bamboo chips, coconut fibers, and traditional Chinese medicinal materials.
mode: Electric motor
power:15-110kw
output:0.05-1t/h
8615638887818
video Ultrafine grinding mill
Performance parameters
Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

Ultrafine grinding mill

model power(KW) Rotational speed(R/MIN) Size after crushing(mesh) Production capacity(KG/H) Equipment weight(KG) Size after crushing(M)
GRT500 15/18.5 3800 30-2000 50-150 1200 1.5*2.2*2.8
GRT600 22-30 100-250 1600 1.7*2.3*2.8
GRT700 37-45 200-400 2000 2*2.4*2.8
GRT800 55-75 300-600 2400 2.2*2.5*2.8
GRT900 75-90 3600 400-800 2800 2.4*2.6*3
GRT1000 90-110 500-1000 3000 2.6*2.6*3
Note: The product is constantly being updated, upgraded and improved. In case of any differences between the accompanying pictures, feature descriptions and performance parameters and the actual model, the physical product shall prevail.
